Home ProductsHand Lifting Winch

Heavy Duty Hand Lifting Winch For Hoist 250kg , Brake Hand Winch

Heavy Duty Hand Lifting Winch For Hoist 250kg , Brake Hand Winch

    • Heavy Duty Hand Lifting Winch For Hoist 250kg , Brake Hand Winch
    • Heavy Duty Hand Lifting Winch For Hoist 250kg , Brake Hand Winch
  • Heavy Duty Hand Lifting Winch For Hoist 250kg , Brake Hand Winch

    Product Details:

    Place of Origin: CHINA
    Brand Name: SEAGULL
    Certification: GS/CE
    Model Number: VL

    Payment & Shipping Terms:

    Minimum Order Quantity: 5 PCS
    Price: Negotiation
    Packaging Details: Packed in carton firstly,and then reinforced with steel case for outer packing
    Delivery Time: 30 working days after received your payment
    Payment Terms: L/C, D/A, D/P, T/T
    Supply Ability: 12,000pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Hand Winch Appliation: Warehouse, Building, Wharf, Ect.
    Capacity: 250kg - 1500kg Surface: Painting, Chorme
    Standard: GS/CE Type: Manual

    Product Description



    250KG - 1500KG HAND WINCH

    Multiple application winch to raise or lower boats, sailboat keels, grain augers and more. Automatic brake holds load in position when handle is released.



    Advantages



    series manual winch is a kind of machine tool, it is through the shook with dynamic winch drum to pull the goods. Gear drive by the winch steel wire rolling through the rotation on it to pull the rope goods, its biggest advantage is mainly manifested in the two aspects.

    1. Safety

    It has to be automatic braking device that, when the wire rope hoist shuthelah goods, and winch drum to keep still, brake will automatically open, this makes operate up more human nature more security.

    2. Convenience

    Its another biggest advantage is easy to carry , when need to all kinds of rescue work, it can from the car any direction connection, light and strong



    Technical Parameters



    Model 250 kg 500 kg 1000 kg 1500 kg
    Rated load(kg) 250 500 1000 1500
    Single speed/Double speed single single single single
    Hand operated strength(N) 70 75 85 100
    Dimensions (mm) A 115 129 158 185
    B 60 70 101 101
    C 150 195 242 242
    D 261 285 318 346
    E 287 313 348 378
    F 82 106 140 178
    G 140 164 200 238
    H 17 17 17 17
    J 366 417 463 490
    M 350 350 350 350
    R 166 202 274 274
    Φ 5x44 7x42 9x25 12x24
    D.R. 12:1 17:1 26:1 26:1
    Net weight(no wire rope)(kg) 11 16 38 40
