|Place of Origin:||China,Jiangsu|
|Minimum Order Quantity:||50pcs|
|Packaging Details:||carton and pallet|
|Delivery Time:||30 days|
|Payment Terms:||L/C, T/T|
|Supply Ability:||10000 sets per year|
|Power Source:||Electric||Sling Type:||Chain|
electric chain block,
electric chain fall,
Single PH Electric Chain Block
30 years experience Electric Chain Block wholesale manufacturer reliable quality single PH
A. Capacity from 500kg to 5000kg
B. Quality chain is supplied by FEC JAPAN.
C. Most tensile safety hooks without break.
D. Compact and high efficient motor with heat protection device.
E. Push button is with 24v low voltage to guarantee safety.
F. Limit switch.
G. Limit load device are fitted.
H. CE certified.
I. IP54 protection on electric hoist for dust and water proof protection.
HHXG TYPE HOIST:
1) With suspension hook. push, geared or electric trolley.
2) Standard lift height 3 m, control cable 3m
3) Operating voltage 110-440V , 50/60Hz.
4) Low voltage control 24V is standard.
5) High efficient energy-saving motor, asbestos free brake system.
6) Top and bottom hooks are fitted with safety latches as standard.
7) Drop forged steel suspension & load hooks are heat treated and fracture resistant. In case of dangerous overloading or abuse, the hook does not fracture but will slowly yield.
8) Solid chain bucket.
9) Super strong surface hardened chain.
10) Limit switch devices fitted at both top & bottom ends, switch off power automatically to prevent load chain from running out.
11) The unique friction clutch overload protection, which protects the unit from overloading.
12) High quality electric components with safety protection
|Rated load (ton)||0.5||1||2||3|
|Lifting speed (m/min)||5.2||5.2||2.6||1.7|
|Hoist motor 1-phase Output (kw)||0.8||1.2||1.2||1.2|
|Load chain Dia (mm)||7.1||7.1||7.1||7.1|
|Number of falls||1||1||2||3|
|Dynamical Test (KN)||5.5||11||22||33|
|Min headroom MacG (mm)||545||580||740||790|
|Net Weight (kg)||64||65||72||80|
|Major Dimensions (approx) (mm) A||249||249||249||249|
Changshu Seagull Crane&Hoist Machinery Co.,Ltd was established in 1986. And reformed in 2000 by Japan and china-based partners. Seagull has more than 20 years of experiences in the field of electric hoist and chain block.
Seagull is a manufacturer specialized in designning,developing and producing all kinds of wire rope hoist,electric chain hoist, snatch block,manual winch and riggings hardware.
Our actual land area is15,000 sq.m. We have advanced CNC machines,roll thread machines,cylindrical surface grinders,spark erosion machines,milling machines,auto destruction test machine ,automatic endurance test machines ect.
